Cielarkorana
Model: CV-001 Protecting Insert
Features:
- Stop various kinds of blade, knife and spike
- Front & back protection by Sides and shoulders velcro straps
Standard: NIJ0115.00 I; or EN ISO 14876-4 Level 1, i.e. strike energy < E1 (24 J) & E2 (36 J)
| Size/Protection area M2 | S/0.24 | M/0.28 | L/0.3 | XL/0.4 |
|---|---|---|---|---|
| Weight (kg) | 2.3 | 2.6 | 2.8 | 3.7 |
Materials:
Protecting inserts : a flexible metallic strike panel backed by non-woven UHMW-PE felt; Thickness : -5 mm
Jacket : Oxford, Cotton or Nylon Fabric; ( Style and color of jackets up on custom design is possible).
Color: White, Grey, Blue, Black, Green, Camouflage, etc.
Cielarkorana
Model: CV-02 Concealed Stab proof Dual Protecting Vests
Features:
- Stop soft bullets and various kinds of blade, knife & spike
- Front & back protection
- Adjustable by sides and shoulders velcro straps.
- Front and back pockets for hard insert plates to upgrade the protection level
| Size/Protection area M2 | Weight (kg) in various size/protection (M2) | |||
|---|---|---|---|---|
| S/0.24 M2 | M/0.28 M2 | L/0.3 M2 | XL/0.4 M2 |
|
| NIJ 0101.04 IIIA (9mm FMJ RN) NIJ 0115.00, KR1+SP1 (knives+spikes 24/6J) | 2.3 | 2.6 | 2.8 | 3.7 |
| NIJ 0101.04 IIIA (9mm FMJ RN) NIJ 0115.00, KR2+SP2 (knives+spikes 33/50J) | 2.5 | 2.9 | 3.1 | 4.2 |
| NIJ 0101.04 IIIA (.44 Mag JHP)/ NIJ 0115.00, KR1+SP1 (knives+spikes 24/36J) | 2.5 | 2.9 | 3.1 | 4.2 |
Cielarkorana
Model: CVIP- 01 Concealed Stab proof / dual protecting Vests
Materials:
Protecting inserts: a flexible metallic strike panel backed by laminated UHMWPE UD sheets;
Thickness: 10 – 15 mm.
Jacket: Oxford, Cotton or Nylon Fabric; (Style and color of jackets up on custom design is possible).
Color: White, Grey, Blue, Black, Green, Camouflage, etc.
Cielarkorana
Model: COV-01 Outer Wear Dual protecting Vests
Features:
- Stop soft bullets, various kinds of blade, knife & spike, or stop both soft bullets and various kinds of blade, knife and spike
- Front & back protection
- Adjustable by sides and shoulders velcro straps
- Front and back pockets for hard insert plates to upgrade the protection level
The specifications of the outer wear stabproof, bulletproof, or dual protecting vests are similar to the concealed vests of corresponding protection level
Materials : Protecting inserts: UHMW-PE fabrics and a flexible metallic stab panel
Jacket: Oxford or Nylon Fabric; ( Style and color of jackets up on custom design is possible).
Color : White, Grey, Blue, Black, Green, Camouflage, etc.
Optional Models:
Model: COV- 02 Outer Wear Stab proof / Dual Protecting Vests
Model: COV- 03 Outer Wear Stab proof / Dual Protecting Vests
Features :
- Flexible Light-Weight
- Stop various kinds of blade, knife and spike
- Front & back protection by sides and shoulders velcro straps
Style: Concealable vest for VIP undershirt and civilian protective Police and security force vest Tactical vest Military battle vest
| Model No. | Test Ammunition | Nominal Bullet Mass | Min. Bullet Velocity | Fair Hits | Max. Depth of Deformation |
|---|---|---|---|---|---|
| Pulv-01-38S | 38 Special RN LEAD | 10.2 g 158 gr | 259 m/s (850 ft/s) | 6 | 44 mm (1.73 in.) |
| 22 LRHV RN LEAD | 2.6 g 40 gr | 320 m/s (1050 ft/s) |
|||
| Pulv-02-357JS | 357 MAGNUM JSP | 10.2 g 158 gr | 381 m/s (1250 ft/s) | 6 | 44 mm (1.73 in.) |
| 9 mm FMJ | 8.0 g 124 gr | 332 m/s (1090 ft/s) |
|||
| Pulv-03-357FM | 357 MAGNUM FMJ | 10.2 g 158 gr | 425 m/s (1395 ft/s) | 6 | 44 mm (1.73 in.) |
| 9 mm FMJ | 8.0 g 124 gr | 332 m/s (1090 ft/s) |
|||
| Pulv-04-44ML | 44 MAGNUM LEAD SWC GAS CHECK | 15.55 g 240 gr | 426 m/s (1400 ft/s) | 6 | 44 mm (1.73 in.) |
| 9 mm FMJ | 8.0 g 124 gr | 426 m/s (1050 ft/s) |
|||
| Pulv-05-762M | 7.62 mm. 308 Winchester FMJ | 9.7 g 150 gr | 838 m/s (2750 ft/s) | 6 | 44 mm (1.73 in.) |
| Pulv-06-3006AP | 30-06 AP | 10.8 g 166 gr | 868 g (2850 ft/s) | 6 | 44 mm (1.73 in.) |
